The compact and extremely robust RSPE switches comprise a basic device with eight twisted pair ports and four combination ports that support Fast Ethernet or Gigabit Ethernet. (The maximum of 2048 VLANs includes the default VLAN, all additional static VLANs you configure, and any dynamic VLANs the switch creates if you enable GVRP see GVRP.) Note that each port can be assigned to multiple VLANs by using VLAN tagging see VLAN tagging rules. RSPE switches from Hirschmann These flexible RSPE switches enable you to reduce costs by future-proofing your high-performance networks. And, in order to forward the frame, the switch looks up the destination MAC address in the CAM table to find the associated physical port and VLAN. Find the IP address of the next-hop (router) for this destination. The switch will generate an ARP request whenever it needs to associate an IP address to a MAC address to create and forward a frame.
CASE-2: The sender is a host and wants to send a packet to another host on another network. Use ARP to find another host’s physical address. (The default VLAN is also the default Primary VLAN see The primary VLAN.) In addition to the default VLAN, you can configure additional static VLANs by adding new VLAN names and VIDs, and then assigning one or more ports to each VLAN. CASE-1: The sender is a host and wants to send a packet to another host on the same network. (You can reconfigure the switch to support up to 2048 (vids up to 4094) VLANs.) Also, in the default configuration, all ports on the switch belong to the default VLAN and are in the same broadcast/multicast domain.
#Hirschmann switch telnet arp series#
This guide provides information of command-line interface and the application examples of ISCOM series switches.
#Hirschmann switch telnet arp professional#
In the factory default state, support is enabled for up to 256 VLANs. The Raisecom ISCOM series switch command reference is for the networking professional who is responsible for configuring, managing and maintaining ISCOM series switches. The CLI configures and displays port-based and protocol-based VLANs (see Using the CLI to configure port-based and protocol-based VLAN parameters.
NOTE: The Menu interface configures and displays only port-based VLANs.
